SLR Smart Lift Roof – Heavy-Duty Surveying Scanner Hoist System for Elevated 3D Capture

Scan&Go Smart Lift

The SLR Smart Lift Roof is a professional-grade lifting and elevation system engineered for surveyors and geospatial technicians who require precise, elevated 3D laser scanning. Designed for compatibility with leading terrestrial laser scanners, the Smart Lift Roof enables operators to safely raise scanners above obstructions, improve line-of-sight, and capture cleaner datasets in challenging field conditions.

Built with rugged, long-life materials, this lift system offers smooth height adjustment, secure locking, and stable support—ideal for construction sites, BIM teams, forensic mapping, utilities, topographic surveys, and indoor/outdoor reality capture. The Smart Lift Roof helps you maximize scanner performance by reducing shadows, minimizing occlusions, and expanding vertical coverage without compromising safety.

Whether you’re documenting complex structures, scanning rooftops, mapping facilities, or capturing street-level corridors, the SLR Smart Lift Roof delivers professional reliability, enhanced accuracy, and elevated point-cloud results.

Benefits:

By using Smart Lift Roof combined with Level-Plane 16R or 16B and extending the 3D Laser Scanner it’s possible to obtain:

• significant increase of measurement range
• decrease of the scanning sessions number
• saving of surveying time
• more detailed scans by cutting out balcony shadows, trays of windows and high parts, not visible from the ground
• improving measurement quality due to the increased verticality of the gripping point

Smart Lift Roof can be used with any 3D Laser Scanner!

Features:

• Dimensions closed system 4.3’ x 15”
• Extended pole height 4.2' Ft (with LP16 1,70)
• Maximum load of 77lbs
• Weight 68 lbs
• Electrical engines 1
• Radio and Manual Controller
• Power supply 12V 16A
• Temperature limit for use of the equipment -113° F + 122° F
• Temperature limit for the storage of equipment - 122° F + 176° C

Supporting Accessories Available for Purchase

• BLK2GO
• BLK360 Adapters
• Adapters for Leica, Trimble & Faro scanners
• 1’ Aluminum Spacer – highly recommended for easy mounting
• Level-Plane 16 Bluetooth, Radio & Arctic versions
•

 Data Spec Sheet
